FAGOR CUD-23G/2 Combined Refrigerator with GN 2/1 Shelving

A combined refrigerator keeps two temperature zones in one cabinet, allowing chilled storage of different food types without cross-contamination. The unit circulates cold air with a fan, pushing it evenly across every shelf. This forced convection eliminates hot spots and keeps the set temperature stable, even when the door is opened frequently. Off-cycle defrost stops the compressor at intervals, letting any ice melt naturally without manual intervention or additional heaters. The process is automatic and requires no operator input, reducing daily upkeep in a busy kitchen. The operator loads gastronorm trays or loose items onto the six removable shelves. Each shelf is epoxy-coated to resist corrosion and sized for GN 2/1 containers. The shelves slide on built-in rails and can be repositioned or removed for cleaning. Once the load is in place, the electronic control panel is set to the desired temperature between 0 °C and 8 °C. LED lighting inside the cabinet gives a clear view of stored items, making it easy to locate what is needed without holding the door open. The three doors each serve a separate section, so only one section is exposed at a time, cutting cold-air loss. The cabinet is built from stainless steel inside and out, chosen for its resistance to corrosion and ease of sanitising. A 50 mm layer of insulation surrounds the interior, reducing energy use and helping the unit hold temperature during power fluctuations. Adjustable legs allow the refrigerator to sit level on uneven floors, with a height range of 130 mm to 200 mm. The 1301 L volume provides space for large quantities of prepared ingredients, while the 320 kg weight indicates a sturdy construction that stays in place during daily use. The 0.722 kW cooling power is the load the unit draws from the electrical supply, and the 220–240 V rating means it connects to a standard single-phase circuit found in most professional kitchens. The refrigerant R600a/R290a version is available as an alternative, with its own article number. Stainless-steel walls and epoxy-coated shelves wipe clean in seconds between service shifts, leaving no seams or crevices for grease to collect. The stainless steel surfaces wipe clean with standard kitchen sanitiser, and the epoxy-coated shelves can be removed and washed separately. The off-cycle defrost system means no drain pan or manual ice removal is required. The shelves and rails are designed to be taken out without tools, allowing thorough cleaning of the interior. The product is listed in the professional refrigeration section of the catalogue, under combined refrigerators with gastronorm shelving.
