FAGOR CUN-23S Three-Door Upright Freezer with Electric Defrost

A three-door upright freezer built for high-volume professional kitchens, the FAGOR CUN-23S holds over a thousand litres of frozen goods at a steady -22 °C to -18 °C. The refrigeration cycle compresses and expands a hydrocarbon refrigerant, removing heat from the cabinet and rejecting it outside. Forced-air circulation then pushes the cold air evenly across every shelf, preventing hot spots and keeping every item at the same temperature regardless of position or loading level.

To start, the operator loads the shelves—each rated for 40 kg—with trays, boxes or loose product. The electronic control panel is set to the desired temperature within the -22 °C to -18 °C range, and the unit runs continuously, cycling the compressor on and off to maintain the set point. An electric defrost system periodically melts any ice that forms on the evaporator coils, draining the water away without manual intervention. LED lighting inside the cabinet gives a clear view of contents, while the three doors minimise cold-air loss each time the cabinet is opened.

The cabinet is constructed from stainless steel inside and out, with 50 mm of insulation sandwiched between the inner and outer skins. This thickness of insulation slows heat transfer from the kitchen, reducing the compressor workload and keeping energy use in check. Adjustable legs allow the unit to be levelled on uneven floors, and the doors are hinged for right-hand opening as standard.

Inside, eighteen shelf positions spaced at 70 mm intervals can be fitted with either full-width or half-width epoxy-coated shelves. The shelves slide out on runners for easy access and can be removed entirely for cleaning or reconfiguration. The 1109 L net volume is distributed across three separate compartments, each with its own door, so only one section is exposed at a time during normal use.

The 0.735 kW cooling power rating indicates the load the freezer places on the electrical circuit; it requires a dedicated 220–240 V single-phase supply at 50 Hz. The 300 kg weight means the unit is moved on a pallet truck or trolley rather than lifted by hand. Its 1388 mm width and 2067 mm height fit through standard kitchen doorways and under most worktop extractor hoods, while the 739 mm depth leaves room for rear clearance and condensate drainage.

Cleaning is straightforward: the stainless-steel interior and epoxy-coated shelves can be wiped down with standard kitchen sanitiser, and the shelves are removable for thorough washing. The electric defrost system eliminates the need for manual defrosting, so the only routine maintenance is occasional coil cleaning and door-seal inspection to keep the cabinet airtight.

A 60 Hz version with a slightly higher cooling capacity is available as an alternative, but the standard 50 Hz model is the one supplied unless specified otherwise. The freezer is classified as Energy Efficiency Class E under current regulations, reflecting its balance of capacity and power consumption for professional use.

The FAGOR CUN-23S is listed in the professional refrigeration section of the catalogue, alongside other heavy-duty storage units designed for restaurants, hotels and large-scale catering operations.
