Fagor Electric Display Refrigerator AUPT-22G GD for GN 2/1 Trays

A professional display refrigerator with full-height glass doors keeps chilled food visible while maintaining stable temperatures between 0 and 8 °C. Forced-air circulation distributes cold air evenly across every shelf, preventing warm spots and preserving freshness without manual rotation. The system uses a refrigerant that absorbs heat from inside the cabinet and releases it outside, cycling continuously to hold the set temperature regardless of kitchen heat or frequent door openings.

The operator loads GN 2/1 gastronorm trays onto the six epoxy-coated shelves, each adjustable in 55 mm increments across 24 possible positions. The electronic control panel displays the current temperature and allows precise setting within the 0 to 8 °C range. An integrated ECO mode reduces energy consumption during quieter periods, while the HACCP logging system records up to ten temperature alarms or power interruptions for compliance and troubleshooting.

The cabinet is built from AISI 304 stainless steel inside and out, with rounded corners and sloped surfaces that eliminate dirt traps. A built-in drainage channel collects condensation and spillage, directing it to an external outlet for quick cleaning. High-density polyurethane insulation, 80 mm thick, minimises cold loss and keeps the exterior surface cool to the touch even during peak service.

Double-glazed doors with electric anti-condensation heating prevent fogging and reduce heat transfer. Ergonomic handles and automatic door closers cut cold-air loss every time the unit is opened. Adjustable stainless-steel legs level the refrigerator on uneven floors and raise it for mopping underneath. The 1358 mm width, 856 mm depth and 2106 mm height create a footprint that fits standard worktop runs while offering 1332 litres of usable volume.

The 0.436 kW cooling power draws from a 220-240 V, 50 Hz supply, matching the standard single-phase circuit found in commercial kitchens. At 310 kg, the unit requires a solid floor and is typically moved on a pallet truck or sack barrow. The B energy-efficiency rating reflects the balance between cooling performance and electrical consumption, helping to control running costs in high-turnover environments.

Cleaning involves removing the six shelves, wiping down the interior with a damp cloth and approved sanitiser, then flushing the drainage channel with warm water. The exterior stainless steel can be polished with a non-abrasive cleaner to maintain appearance and hygiene.

A 60 Hz version with refrigerant R600a and 0.437 kW cooling power is available as a variant. The unit is designed for GN 2/1 gastronorm trays and fits Fagor's Konnect remote-monitoring system for centralised kitchen management.
